WAC Lighting Pop-In R4DSDN-F9CS-WT 4 in. Square Trim Downlight — 12W / Selectable CCT
The WAC Lighting R4DSDN-F9CS-WT is a versatile 4-inch square trim downlight designed for new construction applications. Delivering selectable color temperatures from 2700K to 5000K, this fixture uses 12 watts of power and features integrated LED technology for efficient lighting.
Key Features
- Selectable CCT: 2700K, 3000K, 3500K, 4000K, 5000K
- Voltage: 120-277V
- Dimming: ELV and TRIAC, 100-5%
- Construction: Die-cast Aluminum with Cold Rolled Steel Junction Box
- Lens: Frosted TIR lens
- Rated Life: 50,000 Hours
- Mounting: New construction housings with hanger bars
- Cut Out: 4 1/8 inches
- Finish: Electrostatically Powder Coated in White or Black
- Standards: ETL, cETL, Wet Location Listed, Title 24 JA8 Compliant, Airtight, IC
Construction & Aesthetics
This downlight features a die-cast aluminum construction with a cold rolled steel junction box, ensuring durability and reliability. The frosted TIR lens provides even light distribution, and the fixture is available in a white or black electrostatically powder-coated finish.
Electrical & Installation
Operating on 120-277V, this downlight supports ELV and TRIAC dimming from 100% to 5%. It includes new construction housings with hanger bars for easy installation and a cutout size of 4 1/8 inches.
Light Output & Performance
With a rated life of 50,000 hours, this fixture provides reliable performance. The selectable CCT feature allows for customization of the lighting environment to suit various needs.
Typical Applications
- Commercial Spaces
- Residential Areas
- Retail Environments
- Hospitality Venues
- Offices
