Description
RAB WP1 Field-Adjustable LED Wall Pack — 29W, 120–277V, Bronze
The RAB WP1FA29 is a versatile and energy-efficient field-adjustable LED wall pack delivering up to 4,283 lumens at 29W. This fixture features adjustable 3000K/4000K/5000K color temperatures, allowing users to select their preferred light color on-site. Operating on a 120–277V universal driver, it includes an integrated selectable on/off photocell to provide automated dusk-to-dawn security lighting. Built with a Wet Location rating and a durable die-cast aluminum housing, it provides a reliable, long-lasting replacement for traditional HID wall packs on building perimeters, pathways, and loading docks.
Key Features
- Wattage: 29W
- Selectable CCT: 3000K / 4000K / 5000K
- Delivered Lumens: 4,009 to 4,283 lumens (up to 146.1 LPW)
- Voltage: 120–277V input
- Dimming: 0–10V dimming standard (dims down to 10%)
- Controls: Integrated 120-277V selectable on/off photocell included
- CRI: 80+
- HID Equivalent: Replaces up to 125W Metal Halide
- Environmental Ratings: IP65 Wet Location rated
- Certifications: DLC Premium Listed, UL Listed, RoHS Compliant, Trade Agreements Act (TAA) Compliant
- Estimated Life: 100,000 hours (L70)
Typical Applications
- Building perimeters and facades
- Security and pathway lighting
- Entryways and man doors
- Commercial and residential exteriors
- HID wall pack replacement
Performance & Light Output
This contractor-friendly wall pack provides high-efficacy illumination ranging from 4,009 to 4,283 lumens depending on the selected color temperature. With an efficacy reaching up to 146.1 lumens per watt, it serves as a powerful yet energy-conscious choice for outdoor applications. The tempered glass lens and surface-mount LEDs ensure consistent light distribution and color uniformity. The LED light engine is rated for 100,000 hours, drastically reducing the frequency of maintenance compared to traditional lighting.
Electrical & Controls
The WP1FA29 operates on a constant current 120–277V AC driver with standard 0–10V dimming. To maximize hands-free efficiency, the fixture includes an integrated button photocell that can be toggled on or off with a simple switch. This allows the light to turn on automatically at night and off during the day, ensuring the area is only illuminated when necessary.
Construction & Durability
Constructed with a rugged die-cast aluminum housing and high-temperature silicone gaskets, this luminaire is designed to withstand harsh outdoor conditions. It is IP65 rated, protecting it against dust ingress and water spray. The bronze finish is formulated for high durability and long-lasting color. It operates safely in extreme temperatures from -40°C (-40°F) to 50°C (122°F).
Installation & Mounting
Designed for easy wall mounting, the WP1FA29 features a traditional footprint that makes it ideal for replacing older HID wall packs. Its compact size (approximately 10.75″ width) and integrated junction box compatibility allow for quick and secure installation on various exterior surfaces.
What’s Included
- RAB WP1FA29 LED Wall Pack (Bronze)
- Integrated Selectable Photocell
