RAB VXLED26DG LED Vaporproof Ceiling Mount Fixture 2,004 Lumens 26W 4900K 120–277V Natural Aluminum

Description

RAB VXLED26DG LED Jelly Jar Vaporproof Ceiling Light — Wet Rated Downlight

The RAB VXLED26DG is an LED jelly jar vaporproof ceiling light designed for wet location use as a downlight. It delivers 2,004 lumens at 26W with a fixed 4900K color temperature and operates on 120–277V. Built for industrial and commercial environments, it features a die-cast aluminum housing with a protective guard and thermal shock-resistant glass globe. This model is TAA compliant and suitable for federally funded projects. Cold weather starting is rated to -40°F (-40°C) with maximum ambient operation up to 104°F (40°C).

Key Features

• Output: 2,004 lumens
• Wattage: 26W (27.1W input)
• CCT: 4900K fixed
• Voltage: 120–277V
• Driver: Constant current, 100–277V, 50/60Hz
• Power Factor: 97.9%
• Wet Location: Suitable for wet locations as a downlight
• TAA Compliant: Meets Trade Agreements Act requirements
• Operating Range: -40°F (-40°C) to 104°F (40°C)
• Rated Life: 100,000 hours (L70)

Typical Applications

• Industrial corridors
• Stairwells
• Utility rooms
• Maintenance areas
• Service and back-of-house spaces
• Wet-rated ceiling installations

Performance & Light Output

Delivers 2,004 lumens with efficacy of 73.9 lm/W. Color rendering is 68 CRI. Rated lifespan is 100,000 hours (L70).

Electrical & Controls

Operates on 120–277V, 50/60Hz constant current driver (100–277V input). Power factor is 97.9%. Dimming is not listed for this model.

Construction & Durability

Die-cast aluminum housing with high-temperature silicone gaskets for sealed construction. Protective guard and thermal shock-resistant glass globe support wet-rated durability. Mercury and UV free; RoHS compliant.

Installation & Mounting

Ceiling-mount vaporproof design with (3) 1/2″ NPS conduit entry points for sealed conduit routing.

Included

• LED fixture
• Protective guard
• Glass globe
