RAB Field-Adjustable Portrait LED Wall Pack — 13-72W Selectable / 480V
The PWLED/480 is an ultra-thin LED portrait wall pack engineered to modernize commercial exteriors while efficiently covering legacy footprints. Operating exclusively on a high-voltage 480V input, it features field-adjustable 13-72W power capabilities, delivering up to 9,694 lumens. Selectable CCT and an integrated photocell offer precise lighting control, making it an ideal energy-saving retrofit for heavy industrial applications.
Key Features
- Wattage: Field-adjustable 72W, 41W, and 13W settings.
- Voltage: Dedicated high-voltage 480V input.
- CCT: Selectable 3000K, 4000K, and 5000K color temperatures.
- Photocell: Integrated dusk-to-dawn sensor with an integrated on/off switch.
- Dimming: Includes a 0-10V dimming control interface.
- Efficacy: Highly efficient operation yielding up to 131 lumens per watt.
- Surge Protection: Robust 6kV line-to-line and 6kV line-to-ground defense.
- Lifespan: Rated for an exceptional 100,000-hour LED lifespan.
- Profile: ADA-compliant footprint extending less than 4 inches from the wall.
Typical Applications
- Industrial facilities and heavy manufacturing plants.
- Commercial building perimeters and facades.
- Parking structure walls and stairwells.
- Corporate campus walkways.
- High-voltage agricultural exteriors.
Performance & Light Output
This portrait luminaire produces up to 9,694 lumens at an efficacy of 131 lumens per watt, providing expansive coverage with excellent uniformity. A specialized textured glass lens mitigates harsh glare while directing light efficiently outward and downward. It maintains a solid >80 CRI for accurate color rendering and is built to last with an impressive 100,000-hour L70 lifespan, minimizing future maintenance and re-lamping efforts.
Electrical & Controls
Powered by a constant current Class 2 driver, this specific model is engineered exclusively for 480V high-voltage commercial electrical systems. It features 0-10V dimming capability for advanced energy management and includes an integrated photocell to automate dusk-to-dawn operation. To ensure reliable performance in demanding environments, the driver is fortified with heavy-duty 6kV surge protection.
Construction & Durability
The rugged die-cast aluminum housing is sealed with a high-temperature silicone gasket to block moisture and debris. Finished in a durable, long-lasting bronze powder coat, the fixture is fully UL Listed for wet locations. Its robust thermal management ensures it operates reliably in extreme ambient temperatures ranging from -40°F up to 104°F.
Installation & Mounting
Built for simple surface wall mounting, the innovative sliding front design allows contractors quick access to the wiring compartment. Its elongated portrait footprint is specifically designed to cover the faded paint and stains left behind by traditional metal halide wall packs, effectively eliminating the need for expensive exterior repainting during retrofits.
What’s Included
- LED Portrait Wall Pack
- Integrated Photocell
- Mounting Hardware
