RAB GUS17 Field Adjustable Wrap Wraparound Light — 90W Configuration
The RAB GUS17-8/MVS/E is a versatile wraparound light offering 90W of power, delivering up to 12,700 lumens with a selectable CCT of 3500K, 4000K, and 5000K. It operates on 120-277V and is suitable for damp locations. This fixture is DLC listed for energy efficiency and rebate eligibility.
Key Features
- Field Adjustability: Easily adjust wattage between 90W, 80W, and 70W to suit various lighting needs.
- Selectable CCT: Choose from 3500K, 4000K, or 5000K for desired color temperature.
- Dimming Capability: Includes 0-10V dimming driver for smooth light level adjustments.
- Battery Backup: Integrated battery backup provides 90 minutes of operation during power outages.
- Motion Sensing: Equipped with a microwave occupancy sensor for energy-saving motion detection.
- Durable Construction: Features a polycarbonate lens and color-coated steel housing for longevity.
- High Efficacy: Achieves an efficacy of 130.5-141.3 lm/W for efficient performance.
- Long Lifespan: Designed for a 100,000-hour LED lifespan based on IES LM-80 results.
- Surge Protection: Includes 1 kV L-N and 2 kV L/N-PG surge protection for electrical safety.
- Remote Control Option: Settings adjustable via remote control (sold separately).
Typical Applications
- Warehouses
- Stairwells
- Passageways
- Industrial Facilities
- Commercial Buildings
Performance & Light Output
This fixture provides a maximum of 12,721 lumens with an efficacy range of 130.5 to 141.3 lm/W. It maintains a color accuracy of 84-86 CRI and offers a long lifespan of 100,000 hours.
Electrical & Controls
Operates on 120-277V with a constant current driver. Supports 0-10V dimming and includes surge protection. Battery backup ensures 90 minutes of light during outages.
Construction & Durability
Constructed with a polycarbonate lens and color-coated steel housing. Rated for use in temperatures up to 122°F (50°C) and suitable for damp locations.
Installation & Mounting
Designed for surface mounting. Can be mounted with v-hooks, which are ordered separately.
What’s Included
- Wraparound Light Fixture
- Integrated Battery Backup
