Description
RAB G3 G3 3 in. Smooth Downlight — 9W / Selectable CCT
The RAB G3 is a versatile 3-inch smooth trim downlight delivering 600 lumens using 9W. It features selectable CCT, allowing adjustments between 2700K and 5000K, making it ideal for various lighting needs. This model is wet rated, ensuring suitability for diverse environments.
Key Features
- Selectable CCT: 2700K/3000K/3500K/4000K/5000K
- Wattage: 9W
- Lumens: 600 lm
- Voltage: 120V
- Beam Angle: 38°±5°
- CRI: >90
- Lifespan: 50,000 hours
- Dimmable: Yes, down to 10% on compatible systems
- Compliance: ENERGY STAR, Title 24 JA8, RoHS
- Environment: Suitable for wet locations
Construction & Aesthetics
This downlight features a smooth trim style with a white finish, constructed from durable metal. The polycarbonate lens ensures even light distribution. It is designed for recessed mounting without the need for additional housing or J-box, making it ideal for both new construction and retrofit applications.
Electrical & Installation
Operating at 120V with a constant current driver, this downlight is dimmable and includes spring-loaded retention clips for secure installation. It is compatible with TRIAC/ELV dimming systems.
Light Output & Performance
With a light output of 600 lumens and a high CRI of over 90, this downlight ensures excellent color accuracy and performance. The beam angle of 38°±5° provides focused illumination.
Typical Applications
- Residential lighting
- Commercial spaces
- Hospitality environments
- Retail settings
- Wet location installations
