Description
Legrand radiant USB Type C Duplex Outlet — White & Power Delivery
The Legrand R26USBPDW is a white USB Type C duplex outlet from the radiant collection, featuring 15A amperage and tamper-resistant technology. This outlet supports 30W Power Delivery through dual USB Type-C ports, ensuring fast charging for compatible devices. It is designed for residential, hospitality, and multi-dwelling unit applications.
Key Features
- Voltage: Operates at 15.0V, 5.0V, and 9.0V for versatile device compatibility.
- Amperage: Rated at 15A for standard electrical use.
- NEMA Configuration: NEMA 5-15R for compatibility with standard plugs.
- Tamper-Resistant: Yes, includes patented shutter system for safety.
- USB Type-C Ports: Two ports providing 30W of power for fast charging.
- Indicator Light: Yellow and green lights show charging status.
- Dimensions: Measures 1.69 in. width, 4.18 in. height, and 1.35 in. depth.
- Certifications: cULus Listed and RoHS Compliant.
- Warranty: Backed by a Limited Lifetime Warranty.
- Installation: Features back and side wire connections with internal pressure plates.
Construction & Interface
This outlet features a satin white finish and is designed to fit seamlessly with screwless wall plates from the radiant collection, which are sold separately. It includes a scalloped cover design and posted side-wire terminal screws for faster installation.
Power & USB Charging
The outlet provides advanced Power Delivery, offering up to 30W through its dual USB Type-C ports. It intelligently detects and delivers the optimal power level for fast charging, with multi-layered overcurrent protection to safeguard devices.
Wiring & Installation
Designed for easy installation, this outlet supports back and side wire connections with internal pressure plates and screw terminals. It accommodates #14 to #10 AWG wire and features a robust mounting strap for secure installation.
