Legrand Adorne Motion Sensor Switch — Graphite & Manual On/Auto Off
The Legrand ASVS12G4, finished in Graphite, is a sophisticated motion sensor switch designed for manual on and automatic off functionality. It operates at 120V and supports a variety of load types including CFL, LED, Halogen, Incandescent, and Fluorescent up to 600W. This switch is suitable for single-pole and 3-way configurations.
Key Features
- Voltage: Operates at 120 VAC, suitable for residential and light commercial applications.
- Load Rating: Handles up to 600W for various lighting types and 1/6 HP for fan motors.
- Sensor Type: Equipped with Passive Infrared (PIR) technology for vacancy sensing.
- Timer Duration: Adjustable from 5 to 30 minutes for automatic shut-off.
- Neutral Wire: Does not require a neutral wire, simplifying installation.
- Poles: Supports both single-pole and 3-way applications.
- Microban Protection: Features antimicrobial technology to inhibit bacterial growth.
- Dimensions: Measures 1.77 in width, 2.66 in height, and 1.85 in depth.
- Finish: Graphite metallic finish for a modern look.
- Installation: Fits standard wall boxes with screw terminal connections.
Construction & Interface
The switch features a sleek Graphite metallic finish and is designed for indoor use. It includes a manual on function with automatic off capabilities. Note that the wallplate is sold separately.
Sensor, Smart & Timer Capabilities
This motion sensor switch uses Passive Infrared (PIR) technology to detect vacancy, automatically turning off lights after a set period. The timer can be adjusted between 5 and 30 minutes, optimizing energy savings.
Wiring & Installation
Installation is straightforward, as the switch does not require a neutral wire. It supports single-pole and 3-way configurations and connects via screw terminals. Designed for use in standard wall boxes.
