GM Lighting LTR-S Specification COB Wet Location LED Tape Light | 16ft | Static White

Description

The LTR-S COBWP (Chip On Board – Wet Location) represents the newest advancement in flexible LED tape technology. Tightly spaced diodes are encapsulated into a single phosphor strip that provides a seamless linear light display with no LED pixelation. This premium 24VDC tape light series is ideal for professional architectural installations in wet locations, available in two power levels and four color temperatures.

Key Features

• Wet Location Rated: IP65 certified, suitable for outdoor and wet environments
• Seamless COB Technology: No LED pixelation for continuous, uniform illumination
• High Color Rendering: 95+ CRI for accurate color representation
• Professional Grade: UL listed, Title 24 compliant when used with specific drivers
• Flexible Installation: Cuttable every 2 inches, 156 LEDs per foot
• Smart Control Ready: Remote control via GM’s LUXcontrol™ App (requires NEMA box)
• Dimmable: Compatible with ELV, MLV, or LUXcontrol dimming systems
• Wide Viewing Angle: 180° beam angle for optimal light distribution
• Factory Certified: 3M adhesive backing for secure mounting

Available Configurations

1.5W per foot models (127-142 lumens/ft):

• 2700K warm white – 127 lm/ft
• 3000K soft white – 127 lm/ft
• 3500K neutral white – 127 lm/ft
• 4000K cool white – 142 lm/ft

3.0W per foot models (255-285 lumens/ft):

• 2700K warm white – 255 lm/ft
• 3000K soft white – 265 lm/ft
• 3500K neutral white – 275 lm/ft
• 4000K cool white – 285 lm/ft

Technical Specifications

• Voltage: 24VDC
• Power: 1.5W or 3.0W per foot
• Color Temperatures: 2700K, 3000K, 3500K, 4000K
• Length: 16 feet per reel (32′-8″ maximum run on a given lead)
• CRI: 95+
• IP Rating: IP65 (wet location approved)
• Class 2 rated

Warranty

5-year warranty when paired with GM power supply

Applications

Perfect for premium residential, hospitality, retail, and commercial installations requiring wet-location capability:

• Outdoor architectural accent lighting and cove lighting
• Covered patios, pergolas, and outdoor living spaces
• Bathroom vanity and mirror lighting
• Pool houses and spa environments
• Retail display cases in humid environments
• Hospitality exterior and landscape features
• Marine and yacht interior/exterior applications
• Any application requiring seamless, dotless illumination in wet conditions

Note: All reels include 48″ lead. Custom leads available – consult factory. Kelvin temperature (color) ±100K.
